Product Description

LOWRANCE HALO20 Radar

SKU: 000-14543-001

Improve your situational recognition as well as collision avoidance with HALO20, a compact dome radar with pulse compression technology that spots collision hazards and also other targets in close and up to 24 nautical miles away. With its little footprint as well as low profile, HALO20 is a fantastic radar for boaters with tiny sportfishing vessels as well as dayboats.
Quality Short-to-Mid-Range Efficiency
Expand your view from the bow of your watercraft up to 24 nautical miles with pulse-compression radar innovation that delivers a powerful mix of short as well as long-range discovery, in addition to exact target meaning with minimal clutter.

Much Better Situational Recognition, Crash Avoidance
HALO20 radar supplies a thorough range of features to improve your situational recognition and also on-water safety. Display picked crash hazards with MARPA target tracking, tracking approximately 10 targets, or 20 in twin range. Whether you're navigating crowded rivers or taking care of poor exposure, HALO20 Radar immediately evaluations your environments to provide you a clear and also present image.

Prepared When You Are.
HALO20 Radar wakes quickly from its low-power standby setting, providing high-speed radar coverage specifically when and also where you need it. Even if your HALO20 Radar is switched off, startup is a matter of seconds, not minutes like conventional pulse radar.

Easy to Use.
Harbour, Offshore, Weather condition and also personalized settings tune HALO20 Radar's innovative signal handling to guarantee that targets can be seen clearly-- also in the hardest ecological conditions.

Trick Features.
10W Pulse Compression.
24 nm range from a small 20-inch dome.
Incomparable brief range.
Radiation risk-free.
Easy procedure with harbour, offshore and also weather mode.
MARPA target monitoring.
InstantOn ™.
Reduced Power Usage.
Guard Areas.
Relevant Items.
Devices.

In the box

Cable, RJ45 To 5 Pin,1.5 m.
5m cord for HALO Dome Radar/ Nemesis ™.
Specs.
Supply Voltage10.5 - 31.2 VDC (12/24V systems) Max Wind Speed100 knots (51 m/s) Power Consumption typical18WWarranty Period2 YearsPower Usage max20WMax Variety, scale24 NMRotation speed24 RPMOperating Temperature level Range-25 ° to +55 ° C( -13 ° to +130 ° F) Beam width4.9 ° H x 25 ° VWeight5.9 kg( 13 pounds) without cableMin Range, scale50 m/ 200 ft/ 50 ydDimensions Diameter510mm (20") Capacities W x H x D510mm dia x 223 mm H. (20" dia x 8.8" H) Recommended Fuse Rating5AHumidity95% RH at 35 ° C( 95 ° F) Approvals ComplianceFCC, Component 47 CFR 80 and 90: RED, Article 3 of Directive 99/5/EC: CE: EN, EN302-248 V2.1.1: Sector Canada, RSS238: RCM (C-Tick): IEC60945 Sec 9.2,9.3, 10.3-10.9, 11.2: IEC60950 Electrical SafetyRadar ModesHarbour, Offshore, Weather, North Up, Course Up, Relative activity, Real MotionWaterproofratingIPX6InterfaceLowrance MFDRadar TechnologyPulse Compression.
